DCN-5
CR or Chloroprene is a homo-polymer of chloroprene or chloro-butadiene. It has excellent mechanical and good abrasion properties even without reinforcing filters and has a reasonable resilience in grades over 60° shore A. It displays good resistance to heat, ozone, and weathering and also gives good adhesion to metal. The recommended operating temperature range is between -40°C to +125° C. It has good resistance to organic hydrocarbons. We also offer flame retardant grades.
Images
Technical Data
Specifications
| Specification | Value |
|---|---|
| Code | DCN-5 |
| Thickness (Mm) | 5 |
| Specific Gravity Gm Cm | 1.45 |
| Shore A Hardness | 60 |
| Tensile Strength Kgcm2 | 40 |
| Elongation | 250 |
| Compresson Set At 70 C For 22 Hrs | 45 |
| Temp Range (°C) | -35 to +80 |
| Colour | Black |
| Maximum Width | 1.2 Mtr |
| Application | Automotive Components, Industrial Seals, Washers, Construction and Industrial Equipment Bases, Vibration Isolation and damping of mechanical equipments, Load matting |
