Series DRC, are suitable for machines having tapped hole in the base. The bolt rests over the dimple provided on the top face of the mount. Dimple size is provided as per the bolt diameter in the machine base.

Model Load (Kg/pc) Bolt Size Dia(D) mm d mm H mm Adjust.Range Applications
DRC1-u 350 M12 x 100 109 87 150 8 Applications: Compressors, Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc.
DRC2-u 600 M16 x 100 150 108 150 8
DRC3-u 900 M16 x 100 170 136 150 10
DRC4-u 1400 M18 x 150 210 161 150 10
DRC5-u 1900 M20 x 150 240 185 150 12
DRC6-u 2500 M20 x 150 270 215 150 12
DRC1-m 450 M12 x 100 109 87 150 8 Applications: Lathe Machines, Machining Centers, CNC Machines, Milling Machines, Precision Grinding Machines, Drilling Machine, Turning Centers, Transfer Lines etc.
DRC2-m 800 M16 x 100 150 108 150 8
DRC3-m 1150 M16 x 100 170 136 150 10
DRC4-m 1750 M18 x 150 210 161 150 10
DRC5-m 2400 M20 x 150 240 185 150 12
DRC6-m 3200 M20 x 150 270 215 150 12
DRC1-p 175 M12 x 100 109 87 155 8 Applications: Measuring & Testing Machines, Surface Plates, Hardness Testers, Microscopes, EDM Machine, Profile Projectors etc.
DRC2-p 300 M16 x 100 150 108 155 8
DRC3-p 500 M16 x 100 170 136 155 10
DRC4-p 700 M18 x 150 210 161 155 10
DRC5-p 950 M20 x 150 240 185 155 12
DRC6-p 1250 M20 x 150 270 215 155 12
DRC1-s2 300 M12 x 100 109 87 160 8 Applications: Medium Presses, Punching Presses, Centreless Grinding Machines, Gear Shapers, High Speed Machines on upper floors.
DRC2-s2 550 M16 x 100 150 108 160 8
DRC3-s2 850 M16 x 100 170 136 160 10
DRC4-s2 1250 M18 x 150 210 161 160 10
DRC5-s2 1700 M20 x 150 240 185 160 12
DRC6-s2 2200 M20 x 150 270 215 160 12
