TPM Series Mounts are designed for industrial machines that require the machines to be placed at a height of 100mm / 150mm for proper cleaning and repairing under the machine as per IMTMA guidelines. This 3-piece wedge mount has an adjustable bolt which moves the center wedge between top and bottom stationery wedges to provide lift, to the top wedge. Anti-Skid plate is provided on the top wedge therefore, machines are installed as free standing. Large supporting surface ensures solidity and rigidity. Vibration reduction is possible through assembling respective Dynemech insulation plates.

Model Load (Kg/pc) Length (L) (mm) Width (B) (mm) Height at mean position (H) (mm) Adjustment range (mm) Applications
DFP1-u 400 105 55 100 / 150 8 Top anti skid plate Da2 & bottom Insulation plate Du.

Applications: Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc.
DFP2-u 900 150 75 100 / 150 10
DFP3-u 1500 200 100 100 / 150 10
DFP4-u 3200 200 200 100 / 150 12
DFP5-u 4000 200 250 100 / 150 18
DFP6-u 6400 250 320 100 / 150 18
DFP7-u 9600 300 400 100 / 150 20
DFP1-m 500 105 55 100 / 150 8 Top anti skid plate Da1 & bottom insulation plates Dm.

Applications: Lathe Machines, Machining Centers, Milling Machines, Precision Grinding Machines, Drilling Machine, Turning Centers, Transfer Lines etc.
DFP2-m 1200 150 75 100 / 150 10
DFP3-m 2000 200 100 100 / 150 10
DFP4-m 4000 200 200 100 / 150 12
DFP5-m 5000 200 250 100 / 150 18
DFP6-m 8000 250 320 100 / 150 18
DFP7-m 12000 300 400 100 / 150 20
DFP1-s2 350 105 55 100 / 150 8 Top anti skid plate Da1 & bottom Insulation plates Ds2

Applications: Medium Presses, Punching Presses, Centreless Grinding Machines, Gear Shapers, High Speed Machines on upper floors.
DFP2-s2 800 150 75 100 / 150 10
DFP3-s2 1400 200 100 100 / 150 10
DFP4-s2 2800 200 200 100 / 150 12
DFP5-s2 3500 200 250 100 / 150 18
DFP6-s2 5500 250 320 100 / 150 18
DFP7-s2 8500 300 400 100 / 150 20
DFP1-i 600 105 55 100 / 150 8 Top anti skid Da2 & bottom insulation plate Di

Applications: Power Presses, Stamping Machines, Shearing Machines, Punching Machines, For Machine with high vertical impact.
DFP2-i 1500 150 75 100 / 150 10
DFP3-i 2500 200 100 100 / 150 10
DFP4-i 5200 200 200 100 / 150 12
DFP5-i 6500 200 250 100 / 150 18
DFP6-i 10000 250 320 100 / 150 18
DFP7-i 15000 300 400 100 / 150 20
DFP1-p 180 105 55 100 / 150 8 Top anti skid Da1 & bottom insulation plate Dp.

Applications: Measuring & Testing Machines, Surface Plates, Hardness Testers, Microscopes, EDM Machine, Profile Projectors etc.
DFP2-p 400 150 75 100 / 150 10
DFP3-p 725 200 100 100 / 150 10
DFP4-p 1450 200 200 100 / 150 12
DFP5-p 1800 200 250 100 / 150 18
DFP6-p 2900 250 320 100 / 150 18
DFP7-p 4400 300 400 100 / 150 20
