The Sandwich mounts comprise of one or more layers of elastomer bonded to flat steel plates. They are designed to withstand very high cpmpressive loads. They are very slim, having large supporting surface area, stackable mounts. The suspended equipment is free to move in all directions. High ratio of axial stiffness to radial stiffness. Very high axial loads.
| Model | Max. Load (kg) | LXB mm | H mm | I mm | Natural Frequiency (Hz) | Bolt |
| DMS1-A | 40 | 85 x 40 | 36 | 25 | 6 | M8 |
| DMS1-B | 50 | 85 x 40 | 36 | 25 | 6 | M8 |
| DMS1-C | 75 | 85 x 40 | 36 | 25 | 6.5 | M8 |
| DMS1-D | 120 | 85 x 40 | 36 | 25 | 6.5 | M8 |
| DMS1-E | 150 | 85 x 40 | 36 | 25 | 7.0 | M8 |
| DMS2-A | 125 | 165 x 55 | 43 | – | 6.5 | – |
| DMS2-B | 250 | 165 x 55 | 43 | – | 6.5 | – |
| DMS2-C | 425 | 165 x 55 | 43 | – | 7.0 | – |
| DMS2-D | 550 | 165 x 55 | 43 | – | 7.0 | – |
| DMS2-E | 800 | 165 x 55 | 43 | – | 7.0 | – |
